2026 Featherlite 9400 3H Bumper Pull Trailer

Condition

New

Model

9400 Horse

Pull Type

Bumper Pull

Length

17' 5"

Width

7'

Height

7' 6"

GVWR

10,400 lbs

Weight

4,380 lbs

Axles

2

Axle Rating

5,200 lbs each

Tires

235/80R16 LRE

Warranty

10-year Limited Structural Warranty
3-year Hitch-to-Bumper Warranty

Stalls

3

Load Style

Slant Load

Features

• Two 5200# Rubber Torsion Axels with Electric Brakes
• 16" 8 Hole Aluminum Wheels w/ ST235/80R16 LRE Tires
• 2 5/16" Coupler Crank Type Jack with Wheel
• LED Clearance Lights and 4 LED Stop/Turn Lights
• LED Load Light Above Rear Load Door with Switch at Rear
• Double Rear Doors with Windows
• Stainless Double Pipe Hardware and No Center Post
• Gravel Guard
• 36" x 74" Square Camper Door with Window & Deadbolt
• Rubber Dock Bumper
• Aluminum Running Boards
• 1 5/8" Side Posts

• 43" Stall Width
• Square Cornered Drop Down Feed Door with Drop Down Bars in Front of Each Horse
• 34 1/4" x 22" Window with Bars Behind Each Horse
• Padded Air Flo Slant Wall Dividers with Shoulder Separator & Spring-Loaded Slam Latch
• Rubber up 44" on Wall in Front of Horses
• Rubber up 48" on Wall Behind Horses
• .090 Aluminum up 48" on the Wall in Front and Behind Horses
• 1 5/8" Wall Insulation
• White .040 Aluminum Lining Above the Wall Rubber
• Interlocking Smooth Extruded Aluminum Floor with Rubber Floor Mats
• One Pop-up Roof Vent per Horse
• Five Tie Rings per Horse Inside
• One Outside Tie Ring per Horse
• LED Light strips

• Folding Rear Tack Wall Lined on Horse Area Side with White Aluminum
• Turf Behind Halter Hooks
• Dressing Room with Clothes Rod
• Turf on Floor
• Brush Tray
• One Swinging Blanket Bar
• Aluminum Halter Hooks
• One Adjustable Saddle Rack for Each Horse

Trailer upgrades

• Warm Blood Height
